INTRODUCTION This is Forerunner, an agile tracked chassis, low noise and easy to control, which could be a good partner for your tank-liked robots. High-strength aluminium alloy tank base, with delicate appearance, higher stability and longer durability. The track robot is made of engineering plastic that basically assured the good elasticity, excellent damping effect and large road grip of the product. What’ s more, it comes with two quality motors to provide high power and speed, which enables your DIY robot car to widely suit all kinds of road surfaces.  To find more interesting functions, you can use this tracked chassis with Arduino microcontrollers or add other electronic components on the base such as, IR sensor, ultrasonic sensor, camera, LED, display, WIFI module, etc. For Arduino fans and smart robot car lovers, this can be a good choice for you!  Note: the tracked chassis is unassembled, you need to get it done by yourself. Install Instruction: SPECIFICATION Product Size: 300 *230 *124 mm(L*W*H) /11.81*9.06*4.89” Base Material: aluminium alloy Processing Method: electroplating Track: engineering plastic Wheel: engineering plastic Package includes: Base: 1 set Motor: 2 Track: 2 Drive Wheel: 2 Driven Wheel: 10 Screw Accessory: 1 set Wrench: 1 Screwdriver: 1 Motor parameter: Input Voltage: 12V Rotation Speed: 160RPM SHIPPING LIST "Forerunner" - Tracked Chassis x1

  The (1.5 inch) 38mm double aluminum omni wheel is the smallest omni-directional wheel in all of our aluminum omni wheels. It is unique as they are able to roll freely in two directions. And this 38mm omni wheel has 8 rollers which is PU coated. Its rollers are more durable, robust and flexible to provide the wheel 360 degree movement easily. The(1.5 inch) 38mm omni wheel can load capacity for it aluminum plates. This 38mm omni wheel apply to the small robot cars , robot platforms, small toys and so on. Key Features: Diameter: 38mm Axial width: 4mm Number of plate: 2 Number of roller: 8 Body material: Aluminum alloy Roller material: PU Load capacity: 2 kg

  The (10 inch) 254mm Aluminum Mecanum Wheel is a heavy duty wheel. Each Wheel is comprised of a series of bearing rollers, mounted so that their axis of rotation is 45 to the axis of the main wheel. As the wheels rotate in sync, the vehicle moves forward or backwards normally. but by spinning pairs of wheels in opposite directions,the rollers diagonally, or spin in a circle. Specifications: Diameter: 10 inches(254mm) Width: 95mm Number of Rollers: 12 Number of Plates: 2 Body Materials: Aluminum alloy Roller Material: Nylon Spacer Material: Aluminum Length of roller: 92mm Diameter of Roller: 38.2mm Load Capacity: >50KG

  The (10 inch) 254mm Aluminum Mecanum Wheel is a heavy duty wheel.Each Wheel is comprised of a series of rollers, mounted so that their axis of rotation is 45 to the axis of the main wheel. As thewheels rotate in sync, the vehicle moves forward or backwardsnormally. but by spinning pairs of wheels in opposite directions,the rollers diagonally, or spin in a circle. Specifications: Diameter: 10 inches(254mm) Width: 95mm Number of Rollers: 12 Number of Plates: 2 Body Materials: Aluminum alloy Roller Material: Nylon Spacer Material: Aluminum Length of roller: 92mm Diameter of Roller: 38.2mm Load Capacity: >50KG

  This is a piece of (4 inch) 100mm left Mecanum wheel with 9 rollers.This wheel is supposed to work together with other 3 Mecanum wheels(1 right,2 left). To make it roll more fluently, its rollers are mounted with ball bearings. Just like the right wheel, it is recommeded to connected to a motor for independent control when assembled on your robot so that it can enables the wheel to propel your robot forward, backward, and directly sideways even while spinning. Specifications: Diameter:4 inches(100mm) width:50mm Number of Rollers:9 Number of Plates:2 Body material:Aluminium alloy Roller material:PP+PE Spacer material:Nylon Length of roller:19mm Load capacity:15Kg Compatible with coupling size link:   6mm universel de montage en aluminium moyeux accouplement  18007   8mm Universal Aluminum hubs 18008:   10mm universal aluminum mounting hub 18009   12mm Universal Aluminum hubs 18010   16mm universal aluminum mounting hubs for shaft 18012   8mm Aluminum Key Hub 18024   10mm Aluminum Key Hub 18025   12mm Aluminum Key Hub 18017   16mm Aluminum Key Hub 18026   10mm Stainless Steel Key Hub 18029   12mm Stainless Steel Key Hub 18030   16mm Stainless Steel Key Hub 18031   6mm new aluminum spacer  with key (hub)18032   8mm new aluminum spacer  with key (hub)18033   10mm new aluminum spacer  with key (hub)18034   1/4″ universal aluminum mounting hubs for shaft 18079   3/8″ universal aluminum mounting hubs for shaft 18080   3/8″ aluminum key hub 18081   1/2″ D-Shaft aluminum hub 18082   1/2″ aluminum key hub 18083   5/8″ aluminum key hub 18084   6mm 3 piece black anodized coupling sets 18005   14mm Stainless Steel Key Hub 18014

  The Mecanum wheel is one design for a wheel which can move in any direction. It is sometimes called the Ilon wheel after its Swedish inventor :Bengt Ilon. This is a piece of right Mecanum wheelm,it is supposed to work together with other 3 Mecanum wheelss(2 left and 1 right).Its rollers are mounted with ball bearings,make it roll more fluently. Specifications: Diameter:4 inches(100mm) width:50mm Number of Rollers:9 Number of Plates:2 Body material:Aluminium alloy Roller material:PP+PE Spacer material:Nylon Length of roller:47mm Load capacity:15Kg Compatible with coupling size link: 6mm universel de montage en aluminium moyeux accouplement  18007 8mm Universal Aluminum hubs 18008: 10mm universal aluminum mounting hub 18009 12mm Universal Aluminum hubs 18010 16mm universal aluminum mounting hubs for shaft 18012 8mm Aluminum Key Hub 18024 10mm Aluminum Key Hub 18025 12mm Aluminum Key Hub 18017 16mm Aluminum Key Hub 18026 10mm Stainless Steel Key Hub 18029 12mm Stainless Steel Key Hub 18030 16mm Stainless Steel Key Hub 18031 6mm new aluminum spacer  with key (hub)18032 8mm new aluminum spacer  with key (hub)18033 10mm new aluminum spacer  with key (hub)18034 1/4″ universal aluminum mounting hubs for shaft 18079 3/8″ universal aluminum mounting hubs for shaft 18080 3/8″ aluminum key hub 18081 1/2″ D-Shaft aluminum hub 18082 1/2″ aluminum key hub 18083 5/8″ aluminum key hub 18084 6mm 3 piece black anodized coupling sets 18005 14mm Stainless Steel Key Hub 18014

The mecanum wheel is one design for a wheel which can move in any direction. It is sometimes called the ilon wheel after its Swedish inventor: Bengt Ilon. This wheel contain a series of rollers which have an axis of rotation at 45° to the plane of the wheel in a plane parallel to the axis of rotation of the wheel attached to its circumference. Specifications: Diameter:4 inches(100mm) width:50mm Number of Rollers:9 Number of Plates:2 Body material:Aluminium alloy Roller material:PP+PE Spacer material:Nylon Length of roller:19mm Load capacity:15Kg Compatible with coupling size link: 6mm universel de montage en aluminium moyeux accouplement  18007 8mm Universal Aluminum hubs 18008: 10mm universal aluminum mounting hub 18009 12mm Universal Aluminum hubs 18010 16mm universal aluminum mounting hubs for shaft 18012 8mm Aluminum Key Hub 18024 10mm Aluminum Key Hub 18025 12mm Aluminum Key Hub 18017 16mm Aluminum Key Hub 18026 10mm Stainless Steel Key Hub 18029 12mm Stainless Steel Key Hub 18030 16mm Stainless Steel Key Hub 18031 6mm new aluminum spacer  with key (hub)18032 8mm new aluminum spacer  with key (hub)18033 10mm new aluminum spacer  with key (hub)18034 1/4″ universal aluminum mounting hubs for shaft 18079 3/8″ universal aluminum mounting hubs for shaft 18080 3/8″ aluminum key hub 18081 1/2″ D-Shaft aluminum hub 18082 1/2″ aluminum key hub 18083 5/8″ aluminum key hub 18084 6mm 3 piece black anodized coupling sets 18005 14mm Stainless Steel Key Hub 18014

The mecanum wheel is one design for a wheel which can move in any direction. It is sometimes called the ilon wheel after its Swedish inventor: Bengt Ilon. This wheel contain a series of rollers which have an axis of rotation at 45° to the plane of the wheel in a plane parallel to the axis of rotation of the wheel attached to its circumference. Specifications: Diameter:4 inches(100mm) width:50mm Number of Rollers:9 Number of Plates:2 Body material:Aluminium alloy Roller material:PP+PE Spacer material:Nylon Length of roller:19mm Load capacity:15Kg Compatible with coupling size link: 6mm universel de montage en aluminium moyeux accouplement  18007 8mm Universal Aluminum hubs 18008: 10mm universal aluminum mounting hub 18009 12mm Universal Aluminum hubs 18010 16mm universal aluminum mounting hubs for shaft 18012 8mm Aluminum Key Hub 18024 10mm Aluminum Key Hub 18025 12mm Aluminum Key Hub 18017 16mm Aluminum Key Hub 18026 10mm Stainless Steel Key Hub 18029 12mm Stainless Steel Key Hub 18030 16mm Stainless Steel Key Hub 18031 6mm new aluminum spacer  with key (hub)18032 8mm new aluminum spacer  with key (hub)18033 10mm new aluminum spacer  with key (hub)18034 1/4″ universal aluminum mounting hubs for shaft 18079 3/8″ universal aluminum mounting hubs for shaft 18080 3/8″ aluminum key hub 18081 1/2″ D-Shaft aluminum hub 18082 1/2″ aluminum key hub 18083 5/8″ aluminum key hub 18084 6mm 3 piece black anodized coupling sets 18005 14mm Stainless Steel Key Hub 18014

The set of 100mm(4 inch) mecanum wheel includes 2 right wheels and 2 left wheels. Each wheel is comprised of 9 rollers. It is driven independently. Mecanum wheel can be capable of moving in any direction, no need to change the directions the wheel spin. Every of the four wheels contain a series of rollers which have an axis of rotation at 45° to the plane of the wheel in a plane parallel to the axis of rotation of the wheel attached to its circumference. Specifications: Number of wheels:4Diameter of each wheel:4 inches(100mm)Width of each wheel:50mmNumber of Rollers each wheel:9Number of Plates each wheel:2Roller Bearing:Ball bearingBody material:Aluminium alloyRoller material:PP+PESpacer material:NylonLength of roller:19mmLoad capacity:45Kg/Set   Compatible with coupling size link: 6mm universel de montage en aluminium moyeux accouplement  18007:http://www.nexusrobot.com/product/6mm-universal-aluminum-mounting-hubs-for-shaft-18007.html 8mm Universal Aluminum hubs 18008:http://www.nexusrobot.com/product/8mm-universal-aluminum-mounting-hubs-for-shaft-18008.html 10mm universal aluminum mounting hub 18009:http://www.nexusrobot.com/product/10mm-universal-aluminum-mounting-hubs-for-shaft-18009.html 12mm Universal Aluminum hubs 18010:http://www.nexusrobot.com/product/12mm-universal-aluminum-mounting-hubs-for-shaft-18010.html 16mm universal aluminum mounting hubs for shaft 18012:http://www.nexusrobot.com/product/16mm-universal-aluminum-mounting-hubs-for-shaft-18012.html 8mm Aluminum Key Hub 18024:http://www.nexusrobot.com/product/8mm-key-hub-18024.html 10mm Aluminum Key Hub 18025:http://www.nexusrobot.com/product/10mm-key-hub-18025.html 12mm Aluminum Key Hub 18017:http://www.nexusrobot.com/product/12mm-key-hub-18017.html 16mm Aluminum Key Hub 18026:http://www.nexusrobot.com/product/16mm-key-hub-18026.html 10mm Stainless Steel Key Hub 18029:http://www.nexusrobot.com/product/10mm-stainless-steel-key-hub-18029.html 12mm Stainless Steel Key Hub 18030:http://www.nexusrobot.com/product/12mm-stainless-steel-key-hub-18030.html 16mm Stainless Steel Key Hub 18031:http://www.nexusrobot.com/product/16mm-stainless-steel-key-hub-18031.html 6mm new aluminum spacer  with key (hub)18032:http://www.nexusrobot.com/product/6mm-new-aluminum-spacer-hub-with-key-18032.html 8mm new aluminum spacer  with key (hub)18033:http://www.nexusrobot.com/product/8mm-new-aluminum-spacer-hub-with-key-18033.html 10mm new aluminum spacer  with key (hub)18034:http://www.nexusrobot.com/product/10mm-new-aluminum-spacer-hub-with-key-18034.html 1/4″ universal aluminum mounting hubs for shaft 18079:http://www.nexusrobot.com/product/14-universal-aluminum-mounting-hubs-for-shaft-18079.html 3/8″ universal aluminum mounting hubs for shaft 18080:http://www.nexusrobot.com/product/38-universal-aluminum-mounting-hubs-for-shaft-18080.html 3/8″ aluminum key hub 18081:http://www.nexusrobot.com/product/38-aluminum-key-hub-18081.html 1/2″ D-Shaft aluminum hub 18082:http://www.nexusrobot.com/product/12-aluminum-key-hub-18082.html 1/2″ aluminum key hub 18083:http://www.nexusrobot.com/product/12-aluminum-key-hub-18083.html 5/8″ aluminum key hub 18084:http://www.nexusrobot.com/product/58-aluminum-key-hub-18084.html 6mm 3 piece black anodized coupling sets 18005：http://www.nexusrobot.com/product/6mm-3-piece-black-anodized-coupling-sets-18005.html 14mm Stainless Steel Key Hub 18014：http://www.nexusrobot.com/product/14mm-stainless-steel-key-hub-18014.html   Download STP Files： 100mm Mecanum wheel

  The set of 100mm(4 inch) mecanum wheel includes 2 right wheels and 2 left wheels. Each wheel is comprised of 9 rollers. It is driven independently. Mecanum wheel can be capable of moving in any direction, no need to change the directions the wheel spin. Every of the four wheels contain a series of rollers which have an axis of rotation at 45° to the plane of the wheel in a plane parallel to the axis of rotation of the wheel attached to its circumference. Specifications: Number of wheels:4 Diameter of each wheel:4 inches(100mm) Width of each wheel:50mm Number of Rollers each wheel:9 Number of Plates each wheel:2 Roller Bearing:Ball bearing Body material:Aluminium alloy Roller material:PP+PE Spacer material:Nylon Length of roller:19mm Load capacity:45Kg/Set Compatible with coupling size link: 6mm universel de montage en aluminium moyeux accouplement  18007 8mm Universal Aluminum hubs 18008 10mm universal aluminum mounting hub 18009 12mm Universal Aluminum hubs 18010 16mm universal aluminum mounting hubs for shaft 18012 8mm Aluminum Key Hub 18024 10mm Aluminum Key Hub 18025 12mm Aluminum Key Hub 18017 16mm Aluminum Key Hub 18026 10mm Stainless Steel Key Hub 18029 12mm Stainless Steel Key Hub 18030 16mm Stainless Steel Key Hub 18031 6mm new aluminum spacer  with key (hub)18032 8mm new aluminum spacer  with key (hub)18033 10mm new aluminum spacer  with key (hub)18034 1/4″ universal aluminum mounting hubs for shaft 18079 3/8″ universal aluminum mounting hubs for shaft 18080 3/8″ aluminum key hub 18081 1/2″ D-Shaft aluminum hub 18082 1/2″ aluminum key hub 18083 5/8″ aluminum key hub 18084 6mm 3 piece black anodized coupling sets 18005 14mm Stainless Steel Key Hub 18014

  The (5 inch) 127mm Double Aluminum Omni Wheel is a robust, durable and double row wheel that provides easy 360° movement, with rotational and sideways maneuverability. This (5 inch) 127mm Double Aluminum Omni Wheel could be mounted to 3WD Triangular 127mm Double Aluminum Omni Wheel mobile robot kit and 3WD 127mm Double Aluminum Omni Wheel Arduino robot kit. Key Features: Diameter: 5 inches(127mm) Axial width: 29mm Number of plate: 2 Number of roller: 22 Body material: Aluminum alloy Roller material: Rubber Roller bearing : Brass tube Roller diameter:19mm Load capacity: 30kg Compatible with coupling size link: 6mm universel de montage en aluminium moyeux accouplement  18007 8mm Universal Aluminum hubs 18008: 10mm universal aluminum mounting hub 18009 12mm Universal Aluminum hubs 18010 16mm universal aluminum mounting hubs for shaft 18012 8mm Aluminum Key Hub 18024 10mm Aluminum Key Hub 18025 12mm Aluminum Key Hub 18017 16mm Aluminum Key Hub 18026 10mm Stainless Steel Key Hub 18029 12mm Stainless Steel Key Hub 18030 16mm Stainless Steel Key Hub 18031 6mm new aluminum spacer  with key (hub)18032 8mm new aluminum spacer  with key (hub)18033 10mm new aluminum spacer  with key (hub)18034 1/4″ universal aluminum mounting hubs for shaft 18079 3/8″ universal aluminum mounting hubs for shaft 18080 3/8″ aluminum key hub 18081 1/2″ D-Shaft aluminum hub 18082 1/2″ aluminum key hub 18083 5/8″ aluminum key hub 18084 6mm 3 piece black anodized coupling sets 18005 14mm Stainless Steel Key Hub 18014

  The mecanum wheel is one design for a wheel which can move in any direction. It is sometimes called the ilon wheel after itsSwedish inventor :Bengt Ilon. This wheel contain a series of rollers which have an axis of rotation at 45° to the plane of the wheel in a plane parallel to the axis of rotation of the wheel attached to its circumference. Specifications: Diameter:127mm Width:51mm Number of Rollers:12 Number of Plates:2 Body material:Aluminium alloy Roller material:Polyurethane Spacer material:Aluminum Load capacity:15KG/each Compatible with coupling size link: 8mm Aluminum Key Hub 18024 10mm Aluminum Key Hub 18025 16mm Aluminum Key Hub 18026 12mm Key Hub 18017 10mm Stainless Steel Key Hub 18029 12mm Stainless Steel Key Hub 18030 16mm Stainless Steel Key Hub 18031 6mm new aluminum spacer  with key (hub)18032 8mm new aluminum spacer  with key (hub)18033

  The mecanum wheel is one design for a wheel which can move in any direction. It is sometimes called the ilon wheel after itsSwedish inventor :Bengt Ilon. This wheel contain a series of rollers which have an axis of rotation at 45° to the plane of the wheel in a plane parallel to the axis of rotation of the wheel attached to its circumference. Specifications: Diameter:127mm Width:51mm Number of Rollers:12 Number of Plates:2 Body material:Aluminium alloy Roller material:Polyurethane Spacer material:Aluminum Load capacity:15KG/set Compatible with coupling size link: 8mm Aluminum Key Hub 18024 10mm Aluminum Key Hub 18025 16mm Aluminum Key Hub 18026 12mm Key Hub 18017 10mm Stainless Steel Key Hub 18029 12mm Stainless Steel Key Hub 18030 16mm Stainless Steel Key Hub 18031 6mm new aluminum spacer  with key (hub)18032 8mm new aluminum spacer  with key (hub)18033

The (5 inch) 127mm Omni-directional wheels are unique as they are able to roll freely in two directions. The Omni-direction wheels allow a robot to convert from a non-holonomic to a holonomic robot. A non-holonomic robot that uses normal wheels has only 2 out of 3 controllable degrees-of-freedom – moving forward/backwards and rotation. Not being able to move side ways makes a robot slower and less efficient in reaching its given goal. Key Features: Diameter: 5 inches(127mm) Axial width: 29mm Number of plate: 2 Number of roller: 22 Body material: Aluminum alloy Roller material: Rubber Roller bearing : Ball bearing Roller diameter:19mm Load capacity: 30kg Compatible with coupling size link: 6mm universel de montage en aluminium moyeux accouplement  18007 8mm Universal Aluminum hubs 18008: 10mm universal aluminum mounting hub 18009 12mm Universal Aluminum hubs 18010 16mm universal aluminum mounting hubs for shaft 18012 8mm Aluminum Key Hub 18024 10mm Aluminum Key Hub 18025 12mm Aluminum Key Hub 18017 16mm Aluminum Key Hub 18026 10mm Stainless Steel Key Hub 18029 12mm Stainless Steel Key Hub 18030 16mm Stainless Steel Key Hub 18031 6mm new aluminum spacer  with key (hub)18032 8mm new aluminum spacer  with key (hub)18033 10mm new aluminum spacer  with key (hub)18034 1/4″ universal aluminum mounting hubs for shaft 18079 3/8″ universal aluminum mounting hubs for shaft 18080 3/8″ aluminum key hub 18081 1/2″ D-Shaft aluminum hub 18082 1/2″ aluminum key hub 18083 5/8″ aluminum key hub 18084 6mm 3 piece black anodized coupling sets 18005 14mm Stainless Steel Key Hub 18014

  The (6 inch) 152mm Double Aluminum Omni Wheel is a robust, durable and double row wheel that provides easy 360° movement, with rotational and sideways maneuverability. This (6 inch) 152mm Double Aluminum Omni Wheel could be mounted to 3WD Triangular 152mm Double Aluminum Omni Wheel mobile robot kit and 3WD 152mm Double Aluminum Omni Wheel Arduino robotics car. Key Features: Diameter: 6 inches(152mm ) Axial width: 29mm Number of plate: 2 Number of roller: 28 Body material: Aluminum alloy Roller material: Rubber Roller bearing : Brass tube Roller diameter:19mm Load capacity: 40kg Compatible with coupling size link: 6mm universel de montage en aluminium moyeux accouplement  18007 8mm Universal Aluminum hubs 18008: 10mm universal aluminum mounting hub 18009 12mm Universal Aluminum hubs 18010 16mm universal aluminum mounting hubs for shaft 18012 8mm Aluminum Key Hub 18024 10mm Aluminum Key Hub 18025 12mm Aluminum Key Hub 18017 16mm Aluminum Key Hub 18026 10mm Stainless Steel Key Hub 18029 12mm Stainless Steel Key Hub 18030 16mm Stainless Steel Key Hub 18031 6mm new aluminum spacer  with key (hub)18032 8mm new aluminum spacer  with key (hub)18033 10mm new aluminum spacer  with key (hub)18034 1/4″ universal aluminum mounting hubs for shaft 18079 3/8″ universal aluminum mounting hubs for shaft 18080 3/8″ aluminum key hub 18081 1/2″ D-Shaft aluminum hub 18082 1/2″ aluminum key hub 18083 5/8″ aluminum key hub 18084 6mm 3 piece black anodized coupling sets 18005 14mm Stainless Steel Key Hub 18014

  The (6 inch) 152mm Omni-directional wheels are unique as they are able to roll freely in two directions. The Omni-direction wheels allow a robot to convert from a non-holonomic to a holonomic robot. A non-holonomic robot that uses normal wheels has only 2 out of 3 controllable degrees-of-freedom – moving forward/backwards and rotation. Not being able to move side ways makes a robot slower and less efficient in reaching its given goal. Key Features: Diameter:6 inches( 152mm ) Axial width: 29mm Number of plate: 2 Number of roller: 28 Body material: Aluminum alloy Roller material: Rubber Roller bearing Materials: Ball bearing Roller diameter:19mm Load capacity: 40kg Compatible with coupling size link: 6mm universel de montage en aluminium moyeux accouplement  18007 8mm Universal Aluminum hubs 18008: 10mm universal aluminum mounting hub 18009 12mm Universal Aluminum hubs 18010 16mm universal aluminum mounting hubs for shaft 18012 8mm Aluminum Key Hub 18024 10mm Aluminum Key Hub 18025 12mm Aluminum Key Hub 18017 16mm Aluminum Key Hub 18026 10mm Stainless Steel Key Hub 18029 12mm Stainless Steel Key Hub 18030 16mm Stainless Steel Key Hub 18031 6mm new aluminum spacer  with key (hub)18032 8mm new aluminum spacer  with key (hub)18033 10mm new aluminum spacer  with key (hub)18034 1/4″ universal aluminum mounting hubs for shaft 18079 3/8″ universal aluminum mounting hubs for shaft 18080 3/8″ aluminum key hub 18081 1/2″ D-Shaft aluminum hub 18082 1/2″ aluminum key hub 18083 5/8″ aluminum key hub 18084 6mm 3 piece black anodized coupling sets 18005 14mm Stainless Steel Key Hub 18014

The 152mm Mecanum wheel supposed to work with other 3 Mecanum wheel(2 right,1 left). The mecanum wheels have some rollers mounted along its circumstance and the rubber rollers to avoid slip. Each roller has two bearings allow the wheel to move smoothly and easily in any direction. Specifications: Diameter:6 inches(152mm) Width:55.52mm Number of Rollers:15 Number of Plates:2 Body material:Aluminium alloy Roller material:Nylon+TPR Spacer material:Nylon Length of roller:38.1mm Load capacity:15Kg/Set Compatible with coupling size link: 6mm Hub 18007 8mm Hub 18008 10mm Hub 18009 12mm Hub 18010 16mm Hub 18012 8mm Aluminum Key Hub 18024 10mm Aluminum Key Hub 18025 16mm Aluminum Key Hub 18026 12mm Key Hub 18017 10mm Stainless Steel Key Hub 18029 12mm Stainless Steel Key Hub 18030 16mm Stainless Steel Key Hub 18031 6mm new aluminum spacer  with key (hub)18032 8mm new aluminum spacer  with key (hub)18033 10mm new aluminum spacer  with key (hub)18034 1/4″ universal aluminum mounting hubs for shaft 18079 3/8″ universal aluminum mounting hubs for shaft 18080 3/8″ aluminum key hub 18081 1/2″ D-Shaft aluminum hub 18082 1/2″ aluminum key hub 18083 5/8″ aluminum key hub 18084 6mm 3 piece black anodized coupling sets 18005 14mm Stainless Steel Key Hub 18014

  152mm Mecanum wheel right supposed to work with other 3 Mecanum wheels (2 left,1right). The mecanum wheels have some rollers mounted along its circumstance and the rubber rollers to avoid slip. Each roller has two bearings allow the wheel to move smoothly and easily in any direction. Specifications: Width:55.52mm Diameter:6 inches(152mm) Number of Rollers:15 Number of Plates:2 Body material:Aluminium alloy Roller material:Nylon+TPR Spacer material:Nylon Length of roller:38.1mm Load capacity:15Kg/SET Compatible with coupling size link: 6mm Hub 18007 8mm Hub 18008 10mm Hub 18009 12mm Hub 18010 16mm Hub 18012 8mm Aluminum Key Hub 18024 10mm Aluminum Key Hub 18025 16mm Aluminum Key Hub 18026 12mm Key Hub 18017 10mm Stainless Steel Key Hub 18029 12mm Stainless Steel Key Hub 18030 16mm Stainless Steel Key Hub 18031 6mm new aluminum spacer  with key (hub)18032 8mm new aluminum spacer  with key (hub)18033 10mm new aluminum spacer  with key (hub)18034 1/4″ universal aluminum mounting hubs for shaft 18079 3/8″ universal aluminum mounting hubs for shaft 18080 3/8″ aluminum key hub 18081 1/2″ D-Shaft aluminum hub 18082 1/2″ aluminum key hub 18083 5/8″ aluminum key hub 18084 6mm 3 piece black anodized coupling sets 18005 14mm Stainless Steel Key Hub 18014

  The aluminum mecanum wheel include a series of rollers attached to its circumference, these rollers having an axis of rotation at 45° to the plane parallel to the axis of rotation of the wheel. Mecanum wheel using a standard chssis shape and powering each wheel with a different motor, which can be capable of moving in any direction, no need to change the directions the wheels spin. This design enables the wheel to propel your robot forward, backward and directly sideways. Specifications: Diameter:152.4mm(6 inch) Width:55.52mm Number of Rollers per wheel:15 Number of Plates per wheel:2 Body material: Aluminium alloy Roller material: Nylon+TPR Spacer material: Nylon Length of roller:38.1mm Load capacity per wheel:15Kg Compatible with coupling size link:   8mm Hub 18008 10mm Hub 18009 12mm Hub 18010 16mm Hub 18012 8mm Aluminum Key Hub 18024 10mm Aluminum Key Hub 18025 16mm Aluminum Key Hub 18026 12mm Key Hub 18017 10mm Stainless Steel Key Hub 18029 12mm Stainless Steel Key Hub 18030 16mm Stainless Steel Key Hub 18031 6mm new aluminum spacer  with key (hub)18032 8mm new aluminum spacer  with key (hub)18033 10mm new aluminum spacer  with key (hub)18034 1/4″ universal aluminum mounting hubs for shaft 18079 3/8″ universal aluminum mounting hubs for shaft 18080 3/8″ aluminum key hub 18081 1/2″ D-Shaft aluminum hub 18082 1/2″ aluminum key hub 18083 5/8″ aluminum key hub 18084 6mm 3 piece black anodized coupling sets 18005 14mm Stainless Steel Key Hub 18014

The aluminum mecanum wheel include a series of rollers attached to its circumference, these rollers having an axis of rotation at 45° to the plane parallel to the axis of rotation of the wheel. Mecanum wheel using a standard chssis shape and powering each wheel with a different motor, which can be capable of moving in any direction, no need to change the directions the wheels spin. This design enables the wheel to propel your robot forward, backward and directly sideways.   Specifications: Diameter:152.4mm(6 inch) Width:55.52mm Number of Rollers per wheel:15 Number of Plates per wheel:2 Body material: Aluminium alloy Roller material: TPU Spacer material: Nylon Length of roller:38.1mm Load capacity per wheel:15Kg

This set of (6 inch) 152mm mecanum wheel including 4 pieces that are 2 right wheels and 2 left wheels. One right and left can be assembled on each side of your robot. Each wheel is connected to its own, independent motor and driven independently. Every of the four wheels include a series of rollers attached to its circumference, these rollers having an axis of rotation at 45° to the plane parallel to the axis of rotation of the wheel. Mecanum wheel using a standard chssis shape and powering each wheel with a different motor, which can be capable of moving in any direction, no need to change the directions the wheels spin. This design enables the wheel to propel your robot forward, backward and directly sideways. Specifications: Diameter:152.4mm(6 inch) Width:55.52mm Number of Rollers per wheel:15 Number of Plates per wheel:2 Body material:Aluminium alloy Roller material:Nylon+TPR Spacer material:Nylon Length of roller:38.1mm Load capacity per wheel:15Kg   Compatible with coupling size link: 8mm Hub 18008:http://www.nexusrobot.com/product/8mm-universal-aluminum-mounting-hubs-for-shaft-18008.html 10mm Hub 18009:http://www.nexusrobot.com/product/10mm-universal-aluminum-mounting-hubs-for-shaft-18009.html 12mm Hub 18010:http://www.nexusrobot.com/product/12mm-universal-aluminum-mounting-hubs-for-shaft-18010.html 16mm Hub 18012:http://www.nexusrobot.com/product/16mm-universal-aluminum-mounting-hubs-for-shaft-18012.html 8mm Aluminum Key Hub 18024:http://www.nexusrobot.com/product/8mm-key-hub-18024.html 10mm Aluminum Key Hub 18025:http://www.nexusrobot.com/product/10mm-key-hub-18025.html 16mm Aluminum Key Hub 18026:http://www.nexusrobot.com/product/16mm-key-hub-18026.html 12mm Key Hub 18017:http://www.nexusrobot.com/product/12mm-key-hub-18017.html 10mm Stainless Steel Key Hub 18029:http://www.nexusrobot.com/product/10mm-stainless-steel-key-hub-18029.html 12mm Stainless Steel Key Hub 18030:http://www.nexusrobot.com/product/12mm-stainless-steel-key-hub-18030.html 16mm Stainless Steel Key Hub 18031:http://www.nexusrobot.com/product/16mm-stainless-steel-key-hub-18031.html 6mm new aluminum spacer  with key (hub)18032:http://www.nexusrobot.com/product/6mm-new-aluminum-spacer-hub-with-key-18032.html 8mm new aluminum spacer  with key (hub)18033:http://www.nexusrobot.com/product/8mm-new-aluminum-spacer-hub-with-key-18033.html 10mm new aluminum spacer  with key (hub)18034:http://www.nexusrobot.com/product/10mm-new-aluminum-spacer-hub-with-key-18034.html 1/4″ universal aluminum mounting hubs for shaft 18079:http://www.nexusrobot.com/product/14-universal-aluminum-mounting-hubs-for-shaft-18079.html 3/8″ universal aluminum mounting hubs for shaft 18080:http://www.nexusrobot.com/product/38-universal-aluminum-mounting-hubs-for-shaft-18080.html 3/8″ aluminum key hub 18081:http://www.nexusrobot.com/product/38-aluminum-key-hub-18081.html 1/2″ D-Shaft aluminum hub 18082:http://www.nexusrobot.com/product/12-aluminum-key-hub-18082.html 1/2″ aluminum key hub 18083:http://www.nexusrobot.com/product/12-aluminum-key-hub-18083.html 5/8″ aluminum key hub 18084:http://www.nexusrobot.com/product/58-aluminum-key-hub-18084.html 6mm 3 piece black anodized coupling sets 18005：http://www.nexusrobot.com/product/6mm-3-piece-black-anodized-coupling-sets-18005.html 14mm Stainless Steel Key Hub 18014：http://www.nexusrobot.com/product/14mm-stainless-steel-key-hub-18014.html   Download PDF Files:152mm Aluminum Mecanum WheelMecanum Wheel Download STP Files： 152mm Mecanum wheel

  This set of (6 inch) 152mm mecanum wheel including 4 pieces that are 2 right wheels and 2 left wheels. One right and left can be assembled on each side of your robot. Each wheel is connected to its own, independent motor and driven independently. Every of the four wheels include a series of rollers attached to its circumference, these rollers having an axis of rotation at 45° to the plane parallel to the axis of rotation of the wheel. Mecanum wheel using a standard chssis shape and powering each wheel with a different motor, which can be capable of moving in any direction, no need to change the directions the wheels spin. This design enables the wheel to propel your robot forward, backward and directly sideways. Specifications: Diameter:152.4mm(6 inch) Width:55.52mm Number of Rollers per wheel:15 Number of Plates per wheel:2 Body material: Aluminium alloy Roller material: Nylon+TPR Spacer material: Nylon Length of roller:38.1mm Net weight per wheel:600 Load capacity per wheel:15Kg Compatible with coupling size link: 8mm Hub 18008 10mm Hub 18009 12mm Hub 18010 16mm Hub 18012 8mm Aluminum Key Hub 18024 10mm Aluminum Key Hub 18025 16mm Aluminum Key Hub 18026 12mm Key Hub 18017 10mm Stainless Steel Key Hub 18029 12mm Stainless Steel Key Hub 18030 16mm Stainless Steel Key Hub 18031 6mm new aluminum spacer  with key (hub)18032 8mm new aluminum spacer  with key (hub)18033 10mm new aluminum spacer  with key (hub)18034 1/4″ universal aluminum mounting hubs for shaft 18079 3/8″ universal aluminum mounting hubs for shaft 18080 3/8″ aluminum key hub 18081 1/2″ D-Shaft aluminum hub 18082 1/2″ aluminum key hub 18083 5/8″ aluminum key hub 18084 6mm 3 piece black anodized coupling sets 18005 14mm Stainless Steel Key Hub 18014

  The (8 inch) 203mm double aluminum omni directional wheel has a robust body when compared to plastic omni directional wheel. This wheel can be driven by the hubs, and one wheel can be driven by a hub.The omni direction wheel Used for robot kits, cart wheels, and other applications that require this wheel’s special features. Specifications: Diameter: 8 inches(203mm) Axial Width: 39mm Number of Plates: 2 Number of rollers: 36 Body Material: Aluminum alloy Roller Material: Rubber Roller Bearing: Brass Tube Roller Diameter: 19mm Load Capacity: 50kg Compatible with coupling size link: 6mm universel de montage en aluminium moyeux accouplement  18007 8mm Universal Aluminum hubs 18008: 10mm universal aluminum mounting hub 18009 12mm Universal Aluminum hubs 18010 16mm universal aluminum mounting hubs for shaft 18012 8mm Aluminum Key Hub 18024 10mm Aluminum Key Hub 18025 12mm Aluminum Key Hub 18017 16mm Aluminum Key Hub 18026 10mm Stainless Steel Key Hub 18029 12mm Stainless Steel Key Hub 18030 16mm Stainless Steel Key Hub 18031 6mm new aluminum spacer  with key (hub)18032 8mm new aluminum spacer  with key (hub)18033 10mm new aluminum spacer  with key (hub)18034 1/4″ universal aluminum mounting hubs for shaft 18079 3/8″ universal aluminum mounting hubs for shaft 18080 3/8″ aluminum key hub 18081 1/2″ D-Shaft aluminum hub 18082 1/2″ aluminum key hub 18083 5/8″ aluminum key hub 18084 6mm 3 piece black anodized coupling sets 18005 14mm Stainless Steel Key Hub 18014

The (8 inch) 203mm double aluminum omni directional wheel has a robust body when compared to plastic omni directional wheel. This wheel can be driven by the hubs, and one wheel can be driven by a hub.The omni direction wheel Used for robot kits, cart wheels, and other applications that require this wheel’s special features. Specifications: Diameter: 8 inches(203mm) Axial Width: 39mm Number of Plates: 2 Number of rollers: 36 Body Material: Aluminum alloy Roller Material: Rubber Roller Bearing: Ball bearing Roller Diameter: 19mm Load Capacity: 50kg Compatible with coupling size link: 6mm universel de montage en aluminium moyeux accouplement  18007 8mm Universal Aluminum hubs 18008: 10mm universal aluminum mounting hub 18009 12mm Universal Aluminum hubs 18010 16mm universal aluminum mounting hubs for shaft 18012 8mm Aluminum Key Hub 18024 10mm Aluminum Key Hub 18025 12mm Aluminum Key Hub 18017 16mm Aluminum Key Hub 18026 10mm Stainless Steel Key Hub 18029 12mm Stainless Steel Key Hub 18030 16mm Stainless Steel Key Hub 18031 6mm new aluminum spacer  with key (hub)18032 8mm new aluminum spacer  with key (hub)18033 10mm new aluminum spacer  with key (hub)18034 1/4″ universal aluminum mounting hubs for shaft 18079 3/8″ universal aluminum mounting hubs for shaft 18080 3/8″ aluminum key hub 18081 1/2″ D-Shaft aluminum hub 18082 1/2″ aluminum key hub 18083 5/8″ aluminum key hub 18084 6mm 3 piece black anodized coupling sets 18005 14mm Stainless Steel Key Hub 18014
