OAK-D Short Range PoE with ToF
Luxonis
OAK-D Short Range PoE with ToF
Description
The OAK-D Short Range PoE with ToF is a rugged, PoE-connected depth camera that adds a Time-of-Flight sensor for improved short-range accuracy, built for industrial and outdoor robotic vision where precise close-range depth matters.
Key highlights
- Time-of-Flight depth – a ToF VGA sensor (640x480 @ 30fps) delivers accurate short-range depth and better low-light performance.
- Active stereo – an IR dot projector aids depth on low-texture surfaces.
- Global-shutter color – two OV9782 1MP color global-shutter sensors.
- On-device AI – 4 TOPS of processing power (1.4 TOPS for AI) runs any convertible AI model.
- Industrial PoE – M12 X-coded PoE connector for power and GigE, with an M8 connector for IO.
- Rugged enclosure – IP67-rated for industrial and outdoor use.
Specifications
- IR dot projector
- Time of Flight (ToF) VGA (640x480 @ 30fps)
- Two OV9782 (1 MP Color Global Shutter)
- IP67 rated enclosure
- M12 X-coded connector
- M8 IO connector
- PoE circuitry
Camera specifications
| Spec | Value |
|---|---|
| Sensor | OV9782 |
| DFOV / HFOV / VFOV | 89.5° / 80° / 55° |
| Resolution | 1MP (1280x800) |
| Focus | Fixed-Focus: 19.6 cm - ∞ |
| Max Framerate | 120 FPS |
Main features
- 4 TOPS of processing power (1.4 TOPS for AI)
- Run any AI model, even custom architectured/built ones (models need to be converted)
- Encoding: H.264, H.265, MJPEG, 4K/30FPS, 1080P/60FPS
- Computer vision: warp (undistortion), resize, crop via ImageManip node, edge detection, feature tracking, plus custom CV functions
- Stereo depth perception with filtering, post-processing, RGB-depth alignment, and high configurability
- Object tracking: 2D and 3D tracking with the ObjectTracker node
Connectivity
PoE supplies both power and GigE connectivity, letting cameras communicate over standard networking protocols (TCP, UDP, HTTP, MQTT). On-device flash memory enables standalone mode. The industrial M12 PoE connector handles power and data, while the M8 connector provides IO (USB2, FSIN, STROBE, 5V/GND, GPIO).
Documentation & resources
Full hardware docs and the DepthAI SDK are available from Luxonis.
