Pmod CLP: Character LCD with Parallel Interface

The PmodCLP utilizes a Samsung KS0066 LCD controller to display information to a 16x2 Sunlike LCD panel. Users provide 8 bits of data in parallel to display a variety of characters on the screen.

Note:

Revision A of the PmodCLP requires 5V for proper operation. All other Revisions utilize 3.3V.

Features:

• 16×2 character LCD with parallel interface

• 192 predefined characters including 93 ASCII characters

• Up to 8 user-definable characters

• Read and write capability to and from the display

• Small PCB size for flexible designs 2.3“ × 3.3” (5.8 cm × 8.4 cm)

• Follows Digilent Pmod Interface Specification Type 1

• Library and example code available in resource center

What's Included:

• Pmod CLP
• Custom antistatic Pmod packaging
