OAK-D S2 PoE Fixed Focus
Luxonis
OAK-D S2 PoE Fixed Focus
Description
The OAK-D S2 PoE Fixed Focus is the Series 2 Power-over-Ethernet spatial AI camera from Luxonis, delivering on-device depth and AI over a single Ethernet cable in a compact, lightweight enclosure. Its fixed-focus 12MP color camera and industrial M12 PoE and M8 I/O connectors suit reliable fixed-installation deployments.
Key highlights
- Fixed-focus color camera: 12MP IMX378 focusing from 50 cm to infinity.
- Power-over-Ethernet: full 802.3af, Class 3 PoE compliance with 1000BASE-T (1 Gbps) speeds.
- On-device AI: RVC2 processor delivering 4 TOPS (1.4 TOPS for AI) for standard or custom models.
- Industrial I/O: M12 X-coded PoE connector plus an M8 A-coded connector for USB2, camera IOs (FSIN, STROBE), power and an auxiliary GPIO.
- Stereo depth: global-shutter OV9282 pair with a 7.5 cm baseline reaching ~35 meters.
- Rugged build: 184 g, with an M8 waterproofing cap included when the connector is unused.
Sensor specifications
| Camera Specs | Color camera | Stereo pair |
|---|---|---|
| Sensor | IMX378 | OV9282 |
| Shutter | rolling | global |
| FOV (D/H/V) | 81°/69°/55° | 89.5°/80°/55° |
| Resolution | 12MP (4032x3040) | 1MP (1280x800) |
| Focus | FF: 50cm - ∞ | FF: 19.6cm - ∞ |
| Max Framerate | 60 FPS | 120 FPS |
| Pixel size | 1.55µm x 1.55µm | 3µm x 3µm |
| Lens size | 1/2.3 inch | 1/4 inch |
Dimensions & weight
Weight: 184 g.
Depth perception
The camera has a 7.5 cm stereo baseline. Minimum perceivable distance is ~20 cm (400P, extended), ~35 cm (400P or 800P, extended) or ~70 cm (800P); maximum perceivable distance is ~35 meters. Extended refers to the StereoDepth node running in Extended disparity mode.
Connectivity & power
Powered and connected over Power-over-Ethernet (802.3af, Class 3, 1 Gbps); a PoE injector or switch is required. The M8 auxiliary connector (8-pin A-coded) exposes USB2, FSIN/STROBE camera IOs, power and an auxiliary GPIO; the M12 Ethernet connector is 8-pin X-coded.
Documentation & resources
Full hardware docs and the DepthAI SDK are available from Luxonis.
