Intel® RealSense™ Depth Camera D457

Intel® RealSense™ Depth Camera D457

Intel D457

The Intel® RealSense™ Depth Camera D457 is our first GMSL/FAKRA high bandwidth stereo camera. The D457 has an IP65 grade enclosure protecting it from dust ingress and projected water. D457 has an on-board Maxim serializer chip. A Maxim de-serializer is needed at host side to decode the streams.

Technical Specification:

Note: D457 has an on-board Maxim serializer chip. A Maxim de-serializer is needed at host side to decode the streams.

Use Environment Indoor/Outdoor
Image Sensor Technolog Global Shutter
Ideal Range .6 m to 6 m
Depth Technology Stereoscopic
Minimum Depth Distance (Min-Z) at Max Resolution ~52 cm
Depth Accuracy <2% at 4 m
Depth Field of View (FOV) 87° × 58°
Depth Stream Output Resolution Up to 1280 × 720
Depth Stream Output Frame Rate Up to 90 fps
RGB Frame Resolution 1280 × 800
RGB Frame Rate 30 fps
RGB Sensor Technology Global Shutter
RGB Sensor FOV 90° × 65°
RGB Sensor Resolution 1 MP
Camera Module Intel RealSense Module D450
Vision Processor Board Intel RealSense Vision Processor D4
Form factor Camera Peripheral
Camera Dimension
(Length × Height × Depth)		 124 mm × 29 mm × 36 mm
Connectors GMSL/FAKRA
Mounting Mechanism

– One 1/4‑20 UNC thread mounting point
– Two M4 thread mounting points
– Tripod
