Intel® RealSense™
Intel® RealSense™ Depth Camera D455f
SKU: Intel D455f
₹ 51,899.00
Taxes included.
Shipping calculated at checkout.
Description
The Intel® RealSense™ Depth Camera D455f features our long range D455 with an IR pass filter. The addition of an IR Pass Filter over the lenses resolves repetitive pattern and false object detection due to light reflections.. The SDK 2.0 is designed to allow seamless transitions from one generation to the next and between our cameras.
- Longer range for collision avoidance.
- Matched RGB and Depth images make for easy scan recreations.
- A set of image sensors with an IR pass filter that enable capturing of disparity between images up to 1280 x 720 resolution.
- Support for the cross-platform, open-source Intel® RealSense™ SDK 2.0.
- Integrates an IMU to allow your application to refine its depth awareness in any situation where the camera moves.
The latest release of the Intel® RealSense™ SDK 2.0 is available on our GitHub page at https://github.com/IntelRealSense/librealsense/.
WARNING This product can expose you to Antimony oxide (Antimony trioxide), which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov.
Technical Specification:
| Use Environment | Indoor/Outdoor |
| Image Sensor Technology | Global Shutter |
| Ideal Range | .6 m to 6 m |
| Depth Technology | Stereoscopic |
| Minimum Depth Distance (Min-Z) at Max Resolution | ~52 cm |
| Depth Accuracy | <2% at 4 m |
| Depth Field of View (FOV) | 87° × 58° |
| Depth Stream Output Resolution | Up to 1280 × 720 |
| Depth Stream Output Frame Rate | Up to 90 fps |
| Depth Filter | IR Pass |
| RGB Frame Resolution | 1280 × 800 |
| RGB Frame Rate | 30 fps |
| RGB Sensor Technology | Global Shutter |
| RGB Sensor FOV | 90° × 65° |
| RGB Sensor Resolution | 1 MP |
| Camera Module | Intel RealSense Module D450 |
| Vision Processor Board | Intel RealSense Vision Processor D4 |
| Form factor | Camera Peripheral |
| Camera Dimension (Length × Depth × Height) |
124 mm × 26.8 mm × 29 mm |
| Connectors | USB-C* 3.1 Gen 1* |
| Mounting Mechanism | – One 1/4‑20 UNC thread mounting point – Two M4 thread mounting points – Tripod |
