Orbbec
Femto Mega
SKU: Orbbec Femto-Mega
₹ 82,199.00
Taxes included.
Shipping calculated at checkout.
Description
● Widest Field of View at up to 120° Horizontal and 120° Vertical
● Up to 15 fps at 1021X1024 or 30 fps at 640X576 depth resolution
● Up to 25 fps at 3840X2160 RGB resolution
● PoE, USB 3.0 and IMU supported
● Advanced and accurate sync trigger for multi-sensor network
|
Operating Environment |
Indoor / Semi-outdoor |
|
Depth Technology |
iToF |
|
Depth Range |
0.25-5.46m |
|
IMU |
Supported |
|
SDK |
Orbbec SDK K4A Wrapper Orbbec SDK |
|
Spatial Precision |
<11 mm+0.1% distance |
|
Depth FoV |
WFoV 120° x 120°, NFoV 75° x 65° |
|
Depth Resolution and Frame Rate |
Up to ： 1024 x 1024@15fps |
|
Depth Shutter Type |
Global Shutter |
|
RGB FoV |
80° x 51° |
|
RGB Resolution and Frame Rate |
Up to ：3840 x 2160@30fps |
|
RGB Shutter Type |
Rolling Shutter |
|
Power supply |
DC：12V / 2A USB：5V / 3A POE：802.3at（24W） |
|
Power Consumption |
DC Power + USB data |
|
Connector |
USB 3.0 Type-C Gigabit Ethernet |
|
Protection |
N/A |
|
Multi-device Sync port |
8-pin |
|
Operating Temperature |
10℃ - 25℃ |
|
Weight |
560g |
|
Dimensions (W*H*D) |
115 x 40 x145mm |
|
Installation |
1x 1/4-20 UNC 4x M2.5 |
Femto Mega is a next-generation iToF camera co-developed by Orbbec, Microsoft, and NVIDIA. This programmable multi-mode depth and RGB camera offers real-time streaming of processed images over Ethernet or USB connections. It utilizes Microsoft’s industry-proven ToF technology and the NVIDIA® Jetson™ platform to deliver a comprehensive depth and RGB vision solution without requiring additional processing power.
Femto Mega not only provides OrbbecSDK for enhanced PoE performance but also offers a fully compatible API interface with Microsoft Azure Kinect ecosystem applications. Migration documentation are provided for easy transition.
Femto Mega has achieved large-scale and stable mass production, meeting the needs of applications in logistics, robotic arms, manufacturing, retail, healthcare, and fitness.
