USB-CTR08, Counter/Timer, 8HS, 8DI/O CH

Description

The USB-CTR08 is a high-speed USB counter/timer device from Measurement Computing (MCC), now part of Digilent. It offers eight counter inputs supporting input frequencies up to 48 MHz, software-selectable resolution up to 64 bits, and aggregate scan rates up to 8 MB/s.

• Supports Totalize, Period, Pulse Width, and Timing counter input modes
• Four independent pulse-width modulation (PWM) timer outputs
• Eight bit-configurable digital I/O channels
• Synchronous high-speed reads of digital and counter inputs

Includes DAQami software for out-of-the-box data logging, visualization, and signal generation, plus drivers for Visual C++, C#, VB.NET, DASYLab, LabVIEW, Linux, and Python.

Shipping & Compliance Details

• Country of Origin: HU
• HTS Code: 8471809000
• RoHS Compliant: Yes
