BIGAVR6

The BIGAVR6 development system supports 64- and 100-pin AVR microcontrollers. It comes with the ATMEGA128 microcontroller. The system features a USB 2.0 programmer and many peripheral modules such as touch panel controller, CAN, RTC etc.


In-Circuit Debugger

On-board USB 2.0 programmer. AVRprog2 doesn't use bootloader or any similar software for programming. The whole AVR memory and all pins are available to you. This is a fast USB AVR InSystem programmer ideal for your future projects. Our latest AVRprog2 Programmer is driven and powered by a single USB port on a PC. No additional AC power adapter is needed. The programmer is recognized by Windows, which simplifies the driver installation. The programmer board is specifically designed for In-Circuit Serial Programming (ICSP). The External Programmer and JTAG can be connected and used with the BIGAVR6 development system.

Features

MMC/SD, EEPROM, Temperature sensors

MMC/SD card slot enables you to use MMC/SD memory cards easily. With Serial EEPROM 24AA01 you can store up to 1Kbit of data. Temperature Sensor DS1820 measures temperature from -55°C to 125°C. It is connected to the system via 3-pin socket. Board also features Real-Time Clock (RTC) DS1307 with a battery supply.

Displays and Touch screen

Graphic LCD 128x64 and LCD 2x16 can be easily connected via the on-board connectors. Board also features a Touch Screen controller.

Communication and Interfaces

RS-232 communication is enabled via two DB9 connectors and MAX232 level converters. USB connector and CAN transceiver MCP2551 are provided on-board as well.

PORTs, buttons and LEDs

86 push buttons and 86 LEDs are connected to all microcontrollers pins. DIP switch is used to separate port pins from pull-up/pull-down resistors.

Package Contains

  • BIGAVR6 development system.
  • BIGAVR6 MCU Card with ATMEGA128 Microcontroller
  • Documentation

Specification

Applications Developing and testing firmware, creating prototypes, learning embedded programming
Displays Connector for LCD 2x16 and GLCD 128x64
Graphic controller Embedded inside MCU
Touch Screen Resistive
Architecture AVR (8-bit)
MCU ATMEGA128
On-board modules Socket for DS1820 temperature sensor, A/D Potentiometer, 86 LEDs and push buttons, Real-Time Clock (RTC DS1307),
Programming On-board USB 2.0 programmer for AVR. JTAG port supports in-circuit debugging and firmware programming.
Storage 1KB Serial EEPROM (24AA01), MMC/SD card slot
Expandability 1 x IDC10 header for each PORT
Integration Mounting holes
Input Voltage 5V (via USB) or 9-32V AC, 7-23V DC (via adapter)
