OLED W click
₹ 2,519.00
Skip to product information
Out of stock
MikroElektronika
OLED W click
MIKROE-1649
₹ 2,519.00
Taxes included.
Shipping calculated at checkout.
Description
OLED W click carries a 96 x 39px white monochrome passive matrix OLED display. The display is bright, has a wide viewing angle and low power consumption. To drive the display, OLED W click features an SSD1306 controller. It's built-in functionalities include contrast control, normal or inverse image display, vertical and horizontal scrolling functions and more. OLED W click can communicate with the target board MCU either through SPI or I2C mikroBUS™ lines. You switch between output options by resoldering the onboard SEL COMM jumpers (J1, J2 and J3) to the appropriate position. OLED W click uses a 3.3V power supply.
Specification
| Type | OLED |
| Applications | Ideal for displaying bright and crisp white text or icons |
| On-board modules | SSD1306 controller, 96 x 39px white monochrome passive matrix OLED display |
| Key Features | Monochrome white OLED display, 96 x 39px resolution, 19.3 x 7.8mm active area |
| Key Benefits | Onboard controller enables scrolling, contrast control etc. |
| Interface | SPI,GPIO,I2C |
| Input Voltage | 3.3V or 5V |
| Compatibility | mikroBUS |
| Click board size | M (42.9 x 25.4 mm) |
