MCC E-1608: Multifunction Ethernet DAQ Device

Digilent is now a proud distributor of Measurement Computing Corporation (MCC) DAQ and data logging products. MCC is a leading supplier of data acquisition solutions that are easy-to-use, easy-to-integrate, and easy-to-support.

The E-1608 features 8 SE/4 DIFF analog inputs, 16-bit resolution, 250 kS/s sample rate, two 16-bit analog outputs, eight digital I/O, and one 32-bit counter input.

Software support includes free DAQami software for out-of-the-box data logging, viewing of data, and generating signals. Also freely available are drivers for the most popular applications and programming languages including Visual C++®, Visual C#®, Visual Basic®.NET, DASYLab®, LabVIEW™, Linux®, and Python™.

An OEM, board-only version of the E-1608 with header connectors instead of screw terminals is available and can be ordered directly from MCC.

Features:

• 8 SE/4 DIFF analog inputs
• 16-bit resolution
• 250 kS/s sample rate
• ±10 V, ±5 V, ±2 V, ±1 V input ranges
• Two 16-bit analog outputs
• Eight digital I/O
• One counter input

• Product Compliance:
  • HTC: 8473.30.1180
  • ECCN: 3A992.a

Included:

• E-1608
• Ethernet Cable 1M
• Power Supply, 5 VDC Output
• Field Changeable AC Input Plug (USA style is included, other types may be purchased separately)
• Printed insert: DAQami Quick Start
• MCC packaging assembly/foam, etc.

Software:

Prioritizing on ease of use and flexibility, MCC offers out-of-the-box software plus drivers for the most popular programming languages and applications.

Out-of-the-box software includes DAQami for data logging, visualization, and signal generation. For a more full-featured and customizable experience, DASYLab® provides real-time analysis and control, plus the ability to create custom applications without programming.

DAQami and DASYLab can be purchased directly from MCC.

For maximum customization, drivers are included for Visual C++®, Visual C#®, Visual Basic®.NET, LabVIEW™, MATLAB®, Linux®, and Python™.
