Intel® RealSense™

Intel RealSense Depth Camera D435if

Intel RealSense Depth Camera D435if

SKU:D435if

Regular price Rs. 51,299.00
Regular price Sale price Rs. 51,299.00
Sale Sold out
Taxes included. Shipping calculated at checkout.

Low stock

The D435if is part of the new D400f family that was first introduced by the D435f camera. It adds an IMU to the D435f camera, allowing applications to refine the depth awareness in any situation where the camera moves. D435if features our widest field of view, along with a global shutter and IMU for high-speed depth applications. The addition of an IR Pass Filter over the lenses resolves repetitive pattern and false object detection due to light reflections.

Note: The USB cover has been removed from cameras.

d435fv2











Features Use environment:
Indoor/Outdoor

Ideal Range:
.3 m to 3 m

Depth Depth technology:
Stereoscopic

Minimum Depth Distance (Min-Z) at Max Resolution:
~28 cm

Depth Accuracy:
<2% at 2 m(2)

Image sensor technology:
Global Shutter
Depth Field of View (FOV):
87° × 58°(1)

Depth output resolution:
Up to 1280 × 720

Depth frame rate:
Up to 90 fps
Filter Depth Filter
IR Pass
RGB Filter
IR Cut
RGB RGB frame resolution:
Up to 1920 × 1080

RGB frame rate:
30 fps

RGB sensor technology:
Rolling Shutter
RGB sensor FOV (H × V):
69 × 42°(1)

RGB sensor resolution:
2 MP
Major Components Camera module:
Intel RealSense Module D430 + RGB Camera
Vision Processor Board:
Intel RealSense Vision Processor D4 with an IMU
Physical Form factor:
Camera Peripheral

Length × Depth × Height:
90 mm × 25.8 mm × 25 mm



Connectors:
USB‑C* 3.1 Gen 1*

Mounting mechanism:
– One 1/4‑20 UNC thread mounting point
– Two M3 thread mounting points
