FX2 Module Interface Board

The Digilent FX2 Module Interface Board (FX2 MIB) offers a ready-made solution for interfacing peripheral modules to Digilent system boards.

Stats:

Connector(s):

• Hirose FX2
• Four 12-pin Pmod
• Two 6-pin Pmod

Features:

• Provides 6 additional Pmod™ connectors (four 12-pin and two 6-pin)

• Based on the Hirose FX2 peripheral board connector

• Access to JTAG scan chain

• Access to signals for test points

• Provision for oscillator for clock input to system board
